Multimode optical fibers (MMF) are standardized into categories OM1 through OM5, each defined by core size, modal bandwidth, and supported data rates, with standards set by ISO/IEC, EN, and IEC.Overview of Multimode Fiber

Multimode optical fiber (MMF) is designed for short- to medium-distance data transmission, typically within buildings, campuses, or data centers. MMF has a larger core diameter (50–100 µm) than single-mode fiber, allowing multiple light modes to propagate simultaneously. This design simplifies alignment and installation, making MMF cost-effective and ideal for high-speed applications over distances up to 550 meters depending on fiber type and data rate . MMF is commonly paired with LEDs or VCSELs as light sources, reducing system cost while maintaining reliable performance .

Standardization of Multimode Fiber

Multimode fibers are standardized by several organizations:

  • ISO/IEC 11801 and EN 50173-1 define fiber categories and performance values for cabled fibers .
  • IEC 60793-2-10 specifies the technical characteristics of individual fibers, including bend-insensitive and standard multimode fibers .
  • ITU-T G.651.1 defines widely used forms of multimode fiber for communication .
Fiber Categories (OM1–OM5)

Multimode fibers are classified into five generations:

  • OM1: 62.5 µm core, LED source, suitable for legacy 1G Ethernet; orange jacket; largely obsolete for modern high-speed networks .
  • OM2: 50 µm core, LED source, supports 1G and limited 10G Ethernet; orange jacket .
  • OM3: Laser-optimized 50 µm core, designed for VCSELs, supports 10G–40G Ethernet over 300 m; aqua jacket .
  • OM4: Enhanced laser-optimized 50 µm core, supports 10G–100G Ethernet over 550 m; aqua jacket; ideal for high-performance data centers .
  • OM5: Wideband multimode fiber (WB-MMF), supports short-wavelength division multiplexing (SWDM) from 850–953 nm, enabling 40G–400G Ethernet; lime or green jacket; released in 2016 .
Key Technical Parameters
  • Core diameter: Determines the number of modes and modal dispersion.
  • Modal bandwidth: Defines the maximum data rate over a given distance.
  • Maximum link distance: Varies by fiber type and data rate (e.g., OM3 supports 10G up to 300 m, OM4 up to 550 m), .
  • Light source compatibility: OM1/OM2 use LEDs; OM3–OM5 optimized for VCSELs and SWDM transceivers .
Applications

Multimode fibers are widely used in:

  • Enterprise networks and data centers for backbone and horizontal cabling.
  • Campus networks connecting buildings over short distances.
  • High-speed computing environments supporting 10G, 25G, 40G, 100G, and emerging 400G Ethernet.
  • Specialized applications like fiber-optic spectroscopy and laser power transmission .
Summary

Multimode optical fiber standards provide a structured framework for selecting the appropriate fiber type based on distance, data rate, and light source. Understanding OM1–OM5 categories, their modal bandwidth, and standardization ensures reliable, cost-effective network design while supporting modern high-speed applications in enterprise and data center environments .
