Fiber optic terminal box with round connector and pigtail

A fiber optic terminal box with round connectors and pigtails is a compact, durable enclosure designed for splicing, terminating, and protecting fiber optic cables in FTTH and small network deployments.Overview

Fiber optic terminal boxes are enclosures that protect optical fiber cables and pigtail connections while providing organized access for technicians. They are typically made from ABS or ABS+PC materials, offering durability and resistance to environmental factors such as dust, moisture, and physical damage, with some models rated up to IP68 waterproofing . These boxes are widely used in telecom rooms, residential broadband networks, office buildings, and industrial facilities .

Key Features

• Connector Types: Round connectors such as FC or ST are commonly used, allowing pigtail cables to be plugged into adapters for flexible optical path deployment .
• Pigtail Integration: The box accommodates fiber pigtails, which are pre-terminated fiber strands that can be spliced to incoming cables. Excess fiber is coiled and stored inside the box to maintain proper bending radius and prevent damage .
• Port Capacity: Available in multiple port configurations, typically ranging from 4 to 48 ports, supporting both single-mode and multimode fibers .
• Mounting Options: Can be wall-mounted or desktop-mounted, providing flexibility for different installation environments .
• Splicing and Termination: Supports fusion splicing of fiber cables and pigtails, with compartments to protect splicing joints and adapters .
• Durability and Safety: Designed to maintain a minimum bending radius of 20mm for fibers, ensuring signal integrity and long-term reliability .

Applications

• FTTH/FTTB Networks: Ideal for terminating fiber connections in homes or buildings.
• Telecom and Data Centers: Provides organized fiber management in IDF/MDF rooms.
• Industrial and Office Environments: Protects fiber connections in harsh or high-traffic areas.

Example Specifications

• Material: ABS or ABS+PC
• Operating Temperature: -40°C to 85°C
• Box Size: Compact, e.g., 20x11x3.4 cm
• Weight: Approx. 442g
• Connector Standard: TIA/EIA-568-A, IEC 874-1
• Installation: Screw-design for easy tool access, flexible fiber length reserve Fiber optic terminal boxes with round connectors and pigtails provide a reliable, space-saving, and flexible solution for fiber network terminations, ensuring both protection and easy maintenance of optical connections.
